• Rating：12VDC 50mA
• Contact Resistance：100mΩ Max initial
• Insulation Resistance：100mΩ 500VAC for 1min
• Dielectric Strength：250VAC(50/60Hz) for 1min
• Operating Force：300±100gf 400±100gf
• Mechanical Life：1,000,000 cycles 10,0000 cycles
• Travel：0.5±0.3mm(CTR-12) 0.8±0.2mm(CTR-8)
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Mechanical Life | Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|
| RTR-12-M-9-X-V | 12VDC 50mA | 100mΩ Max initial | 100mΩ 500VAC for 1min | 250VAC(50/60Hz) for 1min | 300±100gf 400±100gf | 1,000,000 cycles 10,0000 cycles | 0.5±0.3mm(CTR-12) 0.8±0.2mm(CTR-8) | 暫無(wú) |
| RTR-12-C-9-X-V | 12VDC 50mA | 100mΩ Max initial | 100mΩ 500VAC for 1min | 250VAC(50/60Hz) for 1min | 300±100gf 400±100gf | 1,000,000 cycles 10,0000 cycles | 0.5±0.3mm(CTR-12) 0.8±0.2mm(CTR-8) | 暫無(wú) |
| RTR-85-H-4-X-V | 12VDC 50mA | 100mΩ Max initial | 100mΩ 500VAC for 1min | 250VAC(50/60Hz) for 1min | 300±100gf 400±100gf | 1,000,000 cycles 10,0000 cycles | 0.5±0.3mm(CTR-12) 0.8±0.2mm(CTR-8) | 暫無(wú) |
| RTR-85-M-4-X-V | 12VDC 50mA | 100mΩ Max initial | 100mΩ 500VAC for 1min | 250VAC(50/60Hz) for 1min | 300±100gf 400±100gf | 1,000,000 cycles 10,0000 cycles | 0.5±0.3mm(CTR-12) 0.8±0.2mm(CTR-8) | 暫無(wú) |
